Layout Flow:
Strip material → decoiler → shear and welder → accumulator → forming and sizing machine → flying saw → packing
Moreover, include: electric control system, high frequency welder.

Specification:
Material: low carbon steel and low alloy steel.
Outer diameter of welded pipes: max φ32mm, min.φ10mm
Wall thickness of welded pipes: max 1.5mm, min. 0.4mm
Forming speed: 40-120m/min
Motor: 30KW
HF welder: 100KW solid state
Structure:
